1/01 UDC3300 Limit Controller Product Manual 33
Section 4 – Configuration Prompt Definitions
4.1 Overview
Introduction
This section provides information for all the user configurable parameters
listed in the configuration section. If you aren’t familiar with these
parameters, this section gives you the parameter prompt, the selection or
range of setting that you can make, and a definition of how each parameter
setting affects controller performance. It will also refer you to any other
prompts that might be affected by your selection.
What’s in this
section?
The table below lists the topics that are covered in this section. They are
listed in the order of their appearance in the controller.
Contents See Page
4.1 Overview 33
4.2 Lockout Data Set Up Group 34
4.3 Limit Data Set Up Group 35
4.4 Input 1 Set Up Group 36
4.5 Communications Set Up Group 40
4.6 Alarms Set Up Group 42
4.7 Calibration Data 44
4.8 Status Test Data 44
