36 UDC3300 Limit Controller Product Manual 1/01
4.4 Input 1 Parameters Set Up Group
Introduction
These are the parameters required for input 1; temperature units, decimal
location, actuation, transmitter characterization, high and low range values
in engineering units, filter, burnout, emissivity, and power line frequency.
Input 1 group prompts
Table 4-3 lists all the function prompts in the “INPUT 1” Set Up group
and their definitions.
Table 4-3 Input 1 Group Definitions
Lower Display
Prompt
Upper Display
Range of Setting
or Selection
Parameter
Definition
DECIMAL
XXXX
XXX.X
XX.XX
DECIMAL POINT LOCATION—This selection determines
where the decimal point appears in the display.
None
One Place
Two Places
NOTE: Auto-ranging will occur when one decimal position
has been selected and the value increases above 999.9
but auto-ranging will not similarly occur when two decimal
positions are selected.
UNITS
DEG F
DEG C
NONE
TEMPERATURE UNITS—This selection will be indicated
on the annunciator. What display of temperature do you
want.
Degrees Fahrenheit
Degrees Celsius
None
Continued on next page
