Honeywell UDC3300 Product Manual

1/01 UDC3300 Limit Controller Product Manual 37
4.4 Input 1 Parameters Set Up Group, Continued
Input 1 group
prompts, continued
Table 4-3 Input 1 Group Definitions, Continued
Lower Display
Prompt
Upper Display
Range of Setting
or Selection
Parameter
Definition
IN1 TYPE
B TC
E TC H
E TC L
J TC H
J TC L
K TC H
K TC L
NNM H
NNM L
NM90 H
NM90 L
NIC TC
R TC
S TC
T TC H
T TC L
W TC H
W TC L
100 PT
100 LO
200 PT
500 PT
RAD RH
RAD RI
0-20mA
4-20mA
0-10mV
0-50mV
0-5 V
1-5 V
0-10 V
INPUT 1 ACTUATION TYPE—This selection determines
what actuation you are going to use for input one.
B thermocouple 0 to 3300°F –18 to 1816°C
E thermocouple high–454 to 1832°F –270 to 1000°C
E thermocouple low –200 to 1100°F –129 to 593°C
J thermocouple high 0 to 1600°F –18 to 871°C
J thermocouple low 20 to 770°F –7 to 410°C
K thermocouple high 0 to 2400°F –18 to 1316°C
K thermocouple low –20 to 1000°F –29 to 538°C
NNM NiNiMo
thermocouple high 32 to 2500°F 0 to 1371°C
NNM NiNiMo
thermocouple low 32 to 1260°F 0 to 682°C
NiMo-NiCo
thermocouple high 32 to 2500°F 0 to 1371°C
NiMo-NiCo
thermocouple low 32 to 1260°F 0 to 682°C
NIC Nicrosil-Nisil
thermocouple 0 to 2372°F –18 to 1300°C
R thermocouple 0 to 3100°F –18 to 1704°C
S thermocouple 0 to 3100°F –18 to 1704°C
T thermocouple high–300 to 700°F –184 to 371°C
T thermocouple low –200 to 500°F –129 to 260°C
W5W26 thermocouple
high 0 to 4200°F –18 to 2315°C
W5W26 thermocouple
low 0 to 2240°F –18 to 1227°C
100 Ohm–RTD –300 to 1200°F –184 to 649°C
100 Ohm RTD low –300 to 300°F –184 to 149°C
200 Ohm RTD –300 to 1200°F –184 to 649°C
500 Ohm–RTD –300 to 1200°F –184 to 649°C
Radiamatic (Type RH) 0 to 3400°F –18 to 1871°C
Radiamatic (Type RI)
0 to 20 Milliamps*
4 to 20 Milliamps*
0 to 10 Millivolts*
0 to 50 Millivolts*
0 to 5 Volts*
1 to 5 Volts*
0 to 10 Volts*
*not available for FM models
Continued on next page
