28 UDC3300 Limit Controller Product Manual 1/01
3.8 Input 1 Group, Continued
Function prompts,
continued
Table 3-5 lists all the function prompts in the “INPUT 1” Set Up group.
Table 3-5 Input 1 Group Function Prompts, Continued
Function Prompt
Lower Display
Function
Name
Selections or
Range of Setting
Upper Display
Factory Setting
BIAS IN1
Input 1 Bias FM: –10.0 to +10.0
Non-FM: –999. to 9999.
0
FILTER 1
Input 1 Filter 0 to 120 seconds 0
BURNOUT
Burnout Protection Burnout is fixed.
For non-linear inputs:
High Limit Control = Upscale
Low Limit Control = Downscale
UPSCALE for FM
EMISSIV
Emissivity 0.01 to 1.00 0
PWR FREQ
Power Line Frequency 60 Hz
50 Hz
60 Hz
To Next Page
