1/01 UDC3300 Limit Controller Product Manual 43
4.6 Alarms Set Up Group, Continued
Alarms group
prompts, continued
Table 4-5 Alarms Group Definitions, Continued
Lower Display
Prompt
Upper Display
Range of Setting
or Selection
Parameter
Definition
A1S2TYPE
Same as A1S1 TYPE ALARM 1 SETPOINT 2 TYPE—Select what you want
Setpoint 2 of Alarm 1 to represent. The selections are the
same as A1S1TYPE.
A2S1TYPE
Same as A1S1 TYPE ALARM 2 SETPOINT 1 TYPE—Select what you want
Setpoint 1 of Alarm 2 to represent. The selections are the
same as A1S1TYPE.
A2S2TYPE
Same as A1S1 TYPE ALARM 2 SETPOINT 2 TYPE—Select what you want
Setpoint 2 of Alarm 2 to represent. The selections are the
same as A1S1TYPE.
A1S1 H L
H I
LO
ALARM 1 SETPOINT 1 STATE—Select whether you want
the alarm type chosen in Prompt "A1S1TYPE" to alarm
High or Low .
HI ALARM
LO ALARM
A1S2 H L
H I
LO
ALARM 1 SETPOINT 2 STATE—Select whether you want
the alarm type chosen in Prompt "A1S2TYPE" to alarm
High or Low .
HI ALARM
LO ALARM
A2S1 H L
H I
LO
ALARM 2 SETPOINT 1 STATE—Select whether you want
the alarm type chosen in Prompt "A2S1TYPE" to alarm
HIGH or LOW.
HI ALARM
LO ALARM
A2S2 H L
H I
LO
ALARM 2 SET POINT 2 STATE—Select whether you
want the alarm type chosen in Prompt "A2S2TYPE" to
alarm HIGH or LOW.
HI ALARM
LO ALARM
AL HYST
0.0 to 5.0% of span or full
output as appropriate
ALARM HYSTERESIS—A single adjustable hysteresis is
provided on alarms such that when the alarm is OFF it
activates at exactly the alarm setpoint; when the alarm is
ON, it will not deactivate until the variable is 0.0% to 5.0%
away from the alarm setpoint.
Configure the hysteresis of the alarms based on INPUT
signals as a % of input range span.
