Chapter 5 – General Operation
Honeywell Confidential: Use or disclosure of information on this page is subject to the restrictions on the title page.
13841 Rev A
183
3. EDIT CHART 3 of 4 is where the new chart coefficients
are edited:
Press the context keys to edit each of the sensitivity and
clock angle coefficients.
IMPLEMENTATION NOTE: Internally, the clock
angles are stored equally spaced around a 360° circle
for each adjustment point. The clock angle shown on
the screen is for adjustment point 1 as shown on the
screen - For Adj Pt 1 (name). The phase angles
for the other adjustment points equally spaced out from
this angle. This algorithm will NOT work for unevenly
spaced adjustment points of the same type. The
Propeller Balance menus may be more appropriate for
? EDIT CHART 1 of 4
Component:
► <MR Side Trkr >
Regime:
► <100% Ground >
Change Type:
► <Pitch Link >
to 2 of 4, push START
? EDIT CHART 3 of 4
A-109EPower
► [ 8.00] flats/IPS
Pitch Link Coeffs
► [10:29] CLOCK ANGLE
For Adg Pt 1 (Tgt )
► RESTORE/RESET FIELD
to 4 of 4, push START
