Removal and Installation
8-15
HP DesignJets 1050C and 1055CM Printers Service Manual
4. Slide the ink cartridge tube connector assembly towards you (refer
to Figure 11).
Figure 11: Ink Cartridge Tube Connector (pulled back)
5. Disconnect the ink cartridge tube connector cable (refer to Figure
12).
Figure 12: Ink Cartridge Tube Connector Cable
1
2082c
1
