HP Designjet 1050c Service Manual

Removal and Installation
8-68
HP DesignJets 1050C and 1055CM Printers Service Manual
NOTE For the following steps refer to Figure 75.
6. Remove the three T-15 screws from the right side of the roller guide
assembly (item 2).
NOTE Be careful not to drop the roller guide once the securing fasteners
have been removed.
7. Remove the three T-15 screws (item 1) from the left side of the
roller guide assembly and remove.
Figure 75: Roller Guide
C607431
1
2

HP Designjet 1050c Specifications

General

Print Technology	Thermal Inkjet
Maximum Print Resolution	1200 x 600 dpi
Number of Ink Cartridges	4 (Cyan, Magenta, Yellow, Black)
Media Types Supported	Coated, glossy, plain, film, vellum, translucent bond
Maximum Media Size	36 in (914 mm) roll
Ink Types	Dye-based
Connectivity	Parallel
Memory	64 MB
Hard Drive	Not available
Media Sizes Supported	A4, A3, A2, A1, A0, B4, B3, B2, B1, B0
Roll Width	24 in, 36 in
Operating Systems Supported	Windows 2000, XP
Power Requirements	100 to 240 VAC (+/- 10%), 50/60 Hz
