59
Tunnel ID: Invalid Interface: vlan-interface 100
BkTunnel ID: Invalid BkInterface: N/A
FtnIndex: 0x0 TrafficIndex: N/A
Connector: N/A
# Display routes destined for 100.1.1.0/24 on Switch B when the link between Switch A and Switch B
fails.
<SwitchB> display ip routing-table 100.1.1.0 24 verbose
Summary Count : 1
Destination: 100.1.1.0/24
Protocol: RIP
Process ID: 1
SubProtID: 0x1 Age: 00h21m23s
Cost: 4 Preference: 100
IpPre: N/A QosLocalID: N/A
Tag: 0 State: Active Adv
OrigTblID: 0x0 OrigVrf: default-vrf
TableID: 0x2 OrigAs: 0
NibID: 0x12000002 LastAs: 0
AttrID: 0xffffffff Neighbor: 192.168.3.2
Flags: 0x1008c OrigNextHop: 192.168.3.2
Label: NULL RealNextHop: 192.168.3.2
BkLabel: NULL BkNextHop: N/A
Tunnel ID: Invalid Interface: vlan-interface 200
BkTunnel ID: Invalid BkInterface: N/A
FtnIndex: 0x0 TrafficIndex: N/A
Connector: N/A
Configuring BFD for RIP (bidirectional detection in BFD
control packet mode)
Network requirements
As shown in Figure 15, VLAN-interface 100 of Switch A and VLAN-interface 200 of Switch C run RIP
process 1.
VLAN-interface 300 of Switch A runs RIP process 2. VLAN-interface 400 of Switch C, and
VLAN-interface 300 and VLAN-interface 400 of Switch D run RIP process 1.
Configure a static route destined for 100.1.1.0/24 on Switch A.
Configure a static route destined for 101.1.1.0/24 on Switch C.
Enable static route redistribution into RIP on Switch A and Switch C. This allows Switch A to
learn two routes destined for 100.1.1.0/24 through VLAN-interface 100 and VLAN-interface 300.
It uses the route through VLAN-interface 100.
Enable BFD on VLAN-interface 100 of Switch A and VLAN-interface 200 of Switch C.
When the link over VLAN-interface 100 fails, BFD can quickly detect the link failure and notify RIP.
RIP deletes the neighbor relationship and the route information received learned on VLAN-interface
100. It uses the route destined for 100.1.1.0/24 through VLAN-interface 300.
