352
# Display detailed information about the route to 1.1.1.1/32 on Switch D. The output shows the
backup next hop for the route.
[SwitchD] display ip routing-table 1.1.1.1 32 verbose
Summary count : 1
Destination: 1.1.1.1/32
Protocol: BGP Process ID: 0
SubProtID: 0x1 Age: 00h00m36s
Cost: 0 Preference: 255
IpPre: N/A QosLocalID: N/A
Tag: 0 State: Active Adv
OrigTblID: 0x0 OrigVrf: default-vrf
TableID: 0x2 OrigAs: 100
NibID: 0x15000003 LastAs: 100
AttrID: 0x1 Neighbor: 2.2.2.2
Flags: 0x10060 OrigNextHop: 2.2.2.2
Label: NULL RealNextHop: 20.1.1.2
BkLabel: NULL BkNextHop: 40.1.1.3
Tunnel ID: Invalid Interface: Vlan-interface 101
BkTunnel ID: Invalid BkInterface: Vlan-interface 201
FtnIndex: 0x0 TrafficIndex: N/A
Connector: N/A
Multicast BGP configuration example
Network requirements
As shown in Figure 79, OSPF runs within AS 100 and AS 200 to ensure intra-AS connectivity. MBGP
runs between the two ASs to exchange IPv4 unicast routes used for RPF check.
Configure the Loopback 0 interface of Switch A and Switch B as the C-BSR and C-RP.
Configure Switch A and Switch B to establish a Multicast Source Discovery Protocol (MSDP)
peer relationship through MBGP, so that the receiver can receive multicast traffic from the
source.
