HPE FlexNetwork MSR Series Comware 7 Layer 3 - Ip Services Configuration Guides

153
Step Command Remarks
3. Add a public IP address
range to the NAT
address group.
address
start-address
end-address
By default, no public IP address ranges
exist.
You can add multiple public IP address
ranges to an address group, but they
cannot overlap.
4. Configure the port range
for the public IP
addresses.
port-range
start-port-number
end-port-number
By default, the port range is 1 to 65535.
The configuration takes effect only on
PAT translation mode.
5. Configure port block
parameters.
port-block block-size
block-size
[
extended-block-number
extended-block-number ]
By default, no port block parameters
exist.
The configuration takes effect only on
PAT translation mode.
6. Return to system view.
quit
N/A
7. Enter interface view.
interface
interface-type
interface-number
N/A
8. Configure DS-Lite
NAT444.
nat outbound ds-lite-b4
{ ipv6-acl-number |
name
ipv6-acl-name }
address-group
group-id
By default, DS-Lite NAT444 is not
configured.
9. Return to system view.
quit
N/A
10. (Optional.) Configure a
PAT mapping mode.
nat mapping-behavior
endpoint-independent
[
acl
{ ipv4-acl-number |
name
ipv4-acl-name } ]
The default mapping mode is
Address
and Port-Dependent Mapping
.
Configuring NAT with DNS mapping
NAT with DNS mapping must operate together with NAT Server and NAT with ALG.
To configure NAT with DNS mapping:
Step Command Remarks
1. Enter system view.
system-view
N/A
2. Configure a DNS
mapping for NAT.
nat dns-map domain
domain-name
protocol
pro-type {
interface
interface-type interface-number |
ip
global-ip }
port
global-port
By default, no DNS mapping for NAT
exists.
You can configure multiple DNS
mappings for NAT.
Configuring NAT hairpin
Configure NAT hairpin on the interface connected to the internal network. NAT hairpin supports P2P
mode and C/S mode.
• To configure the P2P mode, you must configure outbound PAT on the interface connected to the
external network and enable the EIM mapping mode. Internal hosts first register their public
addresses to an external server. Then, the hosts communicate with each other by using the
registered IP addresses.
