HPE FlexNetwork MSR3012 User Manual

392
Field
Description
Protocol Total Flows Packets/Sec
Flow/Sec Packets/flow
Active(sec)/ flow Idle(sec)/flow
Statistics of packets by protocol type:
• Protocol type.
• Total number of flows.
• Number of packets per second.
• Number of flows per second.
• Number of packets per flow.
• Active time (in seconds) of each flow.
• Inactive time (in seconds) of each flow.
Type DstIP(Port) SrcIP(Port) Pro
TC FlowLbl APPID If(Direct) Pkts
Statistics of the active flows in the current cache:
• Flow type. Flows are classified into the following types:
 IP flows.
 Layer 2 flows with IPv6 protocol information (IPL2).
 MPLS flows without IP options (MPLS).
 MPLS flows with IP options (IP&MPLS).
• Destination IPv6 address (destination port).
• Source IPv6 address (source port).
• Protocol number.
• Traffic classification.
• Flow label.
• Application layer protocol ID.
• Interface name (direction).
• Number of packets.
ICMPv6 packets do not contain port number fields, so the type
and code fields are captured. The value for the destination port
represents these two fields:
• The highest 8 bits represent the type field.
• The lowest 8 bits represent the code field.
The value for the source port is set to 0 and does not indicate
any statistics.
DstMAC(VLAN) SrcMAC(VLAN)
Layer 2 information for the active flows in the current cache:
• Destination MAC address.
• Destination VLAN ID.
• Source MAC address.
• Source VLAN ID.
TopLblType(IP/MASK) Lbl-Exp-S-List
Information about the active MPLS flows in the current cache:
• Type of the labels at the top of the label stack:
 IP address associated with the label.
 Mask associated with the label.
• Label list:
 Lbl—20-bit label value.
 Exp—3-bit field for implementing QoS.
 S—1-bit bottom of stack flag. The S field is set to 1 if
the label is the bottom label and set to 0 if not.
