14
•
For the UDP jitter operation, the first 68 bytes of the payload of a UDP packet are for special
purpose. The string fills the remaining part of the payload.
•
For the voice operation, the first 16 bytes of the payload of a UDP packet are for special
purpose. The string fills the remaining part of the payload.
•
For the path jitter operation, the first four bytes of the payload of an ICMP echo request are for
special purpose. The string fills the remaining part of payload.
Examples
# Specify abcd as the payload fill string for ICMP echo requests.
<Sysname> system-view
[Sysname] nqa entry admin test
[Sysname-nqa-admin-test] type icmp-echo
[Sysname-nqa-admin-test-icmp-echo] data-fill abcd
data-size
Use data-size to set the payload size for each probe packet.
Use undo data-size to restore the default.
Syntax
data-size size
undo data-size
Default
The default payload size of a probe packet for different operations is described in Table 5.
Table 5 Default payload size of a probe packet
Operation type
Codec type
Default size (bytes)
ICMP echo N/A 100
UDP echo N/A 100
UDP jitter N/A 100
UDP tracert N/A 100
Path jitter N/A 100
Voice G.711 A-law 172
Voice G.711 µ-law 172
Voice G.729 A-law 32
Views
ICMP/UDP echo operation view
Path/UDP jitter operation view
UDP tracert operation view
Voice operation view
Predefined user roles
network-admin
