8.6 How to replace components
8-21
8. Maintenance and Inspection
5) Mount the end cover.
(For the wireless type, put on Wireless Cable [A] before attaching the end cover
assembly.)
Pay attention to cables when putting on the the end cover so they will not be pinched
at the covers.
How to replace the motor cover assembly
Power I/O connector
Wireless cable [A]
Teaching port
Motor power supply connector
Wireless cable [A]
<End cover assembly: Wireless type>
