ecification
FC Function
Remarks
(Performable operation)
Positioner
mode axis
Simple
direct
mode axis
Direct
numerical
mode axis
Details
• Forced brake release (BKRL)
{ { {
3.9.3.4 (2) [3]
• Push operation mode specification
X X
{
06H
Write
register
• Push direction specification
X X
{
3.9.3.4 (2) [4]
With a move command by direct numerical specification,
the following data is sent in one message:
3.9.3.5 (2)
3.9.3.5 (3)
[1] Position data specification (2 words) X X 2
[2] Positioning band (2 words) X X 2
[3] Speed command (1 word) X X 1
[4] Acceleration/deceleration command (1 word) X X 1
[5] Push-current limiting value (1 word) X X 1
[6] Control signal output (1 word) X X 1
(The content is the same as when the applicable
register is written.)
10H
Write
multiple
registers
simultane-
ously
[7] Send request command data 0 to 3, if a gateway
command is used.
1 each 1 each X 3.9.3.5 (4)
• Positioner mode axes include positioner 1 mode axes and positioner 2 mode axes.
• The value indicates the number of registers (register size: 1 word).
A field that contains a value or “{” indicates that the function is available, while one that contains “X” indicates that the
function is not available.
