(5) The following main screen is displayed.
In the main screen, set the station number (address), baud rate, and operation mode of each axis.
5.1.3 Explanation of the Main Screen
The screen in the setting example is explained by assuming a generic window.
The same screen is used with a CC-Link, DeviceNet, PROFIBUS or RS485SIO system.
[6]
[5]
[4]
[1]
[2] [3]
[9]
[11]
(Check box)
[7]
[8]
[10]
