z Button operations
[1] Tool Communication Setup
Clicking this button opens the communication setup dialog box.
[2] Load
Clicking this button loads the parameters from the GateWayR unit.
[3] Transfer
Transfer to the GateWayR unit the parameters that have been set.
[4] Save
Save the currently set parameters to a file.
[5] Open
Open the saved parameters.
[6] New
Create new parameters.
z Combo box operations
[7] Address
Select and set the address (station number) of the GateWayR unit to be used by the host.
[8] Baud Rate
Select/set an appropriate baud rate when the network type is CC-Link or RS485.
The baud rate is set automatically for all other network types. (The tool shows “Auto.”)
[9] Setting of number of axis
This setting determines the number of occupied stations (CC-Link) or I/O size (DeviceNet, PROFIBUS, RS485).
