3.5 Name/Function of Each Part and External Dimensions
The four types of GateWayR units are exactly the same, except for the field network connector provided on top of the unit.
3.5.1 Name of Each Part
(Front cover open)
User setting
switches
ROBONET communication connector
Power-supply input terminal block
MODE switch LED indicators
Field network connector
(Varies according to the network type)
EMG connector FG terminal
TP connector
