5.3 Specifications
5.3.1 General Specifications
Model RABU
Power-supply voltage
24 VDC
± 10%
Power-supply current MAX 300 mA
Environment Surrounding air temperature
0 to 40
°C
Surrounding humidity 95% RH max. (non-condensing)
Surrounding environment Free from corrosive gases and dust.
Surrounding storage
temperature
0 to 40
°C (If a battery is included, approx. 20°C is desired.)
Surrounding storage humidity 95% RH max. (non-condensing)
Vibration resistance XYZ directions:
10 to 57 Hz, half amplitude – 0.035 mm (continuous)
0.075 mm (intermittent)
57 to 150 Hz – 4.9 m/s
2
(continuous) / 9.8 m/s
2
(intermittent)
Impact resistance XYZ directions: 147 mm/s
2
, 11 ms, half-sine wave pulse
Protection degree IP20
Weight 330 g (including the backup battery)
Outer diameter 34 W x 105 H x 73.3 D [mm]
