5.4 Address Correlation Diagram
The correlation between the PLC’s I/O addresses (internal addresses) and the ROBONET addresses (gateway
addresses) over the network that has been set up is explained for CC-Link, DeviceNet and RS485SIO systems.
5.2 and 5.3 explained an example of network configuration and the configuration procedure. The descriptions in this
section assume the settings used in this example.
A PLC sequence for ROBONET operation can be created based on the applicable settings.
