IAI RoboNet - NameFunction of each Part and External Dimensions; Name of each Part

218
Part 1 S
p
ecification
5.4 Name/Function of Each Part and External Dimensions
5.4.1 Name of Each Part
[6]RCP2 and RCP3 actuator connector
[7]RCA, RCA2 and RCL actuator connector
Front view
[4]Ni-MH battery
[5]Power-supply terminal block
reference battery replacement timining
[1]Status indicator LEDs
[2]Setting switches
[3]Backup battery connector
[8]Host controller connector
[9]ROBONET communication connector
[10]ROBONET communication connector
Down view
