371
Appendix
z Correlation Diagrams of Speed and Load Capacity – Standard Rod Type
Horizontal installation
(N
o
t
e
1)
Vertical installation
High-speed type Medium-speed type Low-speed type
Load capacity (kg)
Speed (mm/sec)
Load capacity (kg)
Speed (mm/sec)
Load capacity (kg)
Speed (mm/sec)
Load capacity (kg)
Speed (mm/sec)
Load capacity (kg)
Speed (mm/sec)
Speed (mm/sec)
(Note) In the above graphs, the number following the type name indicates the lead.
(Note 1) The figures for horizontal installation assume use of an external guide or guides.
Load capacity (kg)
