Icom IC-7800 - Page 202

14-4
D Command table (continued)
14
CONTROL COMMAND
Cmd. Sub Cmd. Data Description
14 11 0000 to
0255
Send/read [AGC] level
(0000=max. CCW to 0255=max. CW)
12 0000 to
0255
Send/read NB level
(0000=0%, 0255=100%)
13 0000 to
0255
Send/read [DIGI-SEL] position
(0000=max. CCW to 0255=max. CW)
14 0000 to
0255
Send/readDRIVEgain
(0000=0%, 0255=100%)
15 0000 to
0255
Send/read Monitor gain
(0000=0%, 0255=100%)
16 0000 to
0255
Send/readVOXgain
(0000=0%, 0255=100%)
17 0000 to
0255
Send/readAntiVOXgain
(0000=0%, 0255=100%)
18 0000 to
0255
Send/read [CONTRAST] position
(0000=max. CCW to 0255=max. CW)
19 0000 to
0255
Send/read BRIGHT level
(0000=0%, 0255=100%)
15 01 00
Read squelch condition (squelch close)
01 Read squelch condition (squelch open)
02 0000 to
0255
Read S-meter level
(0000=S0, 0120=S9, 0241=S9+60 dB)
11 0000 to
0255
Read RF power meter
(0000=0 W, 0143=100 W, 0212=200 W)
12 0000 to
0255
Read SWR meter
( 0000=SWR1.0, 0048=SWR1.5,
0080=SWR2.0)
13 0000 to
0255
Read ALC meter
(0000=0, 0120=Max.)
14 0000 to
0255
Read COMP meter
(0000=0 dB, 0130=15 dB, 0241=30 dB)
15 0000 to
0255
ReadVDmeter
(0151=44V,0180=48V,0211=52V)
16 0000 to
0255
Read ID meter
(0000=0 A, 0165=10 A, 0241=15 A)
16 02 00 Preamp OFF
01 Preamp 1 ON
02 Preamp 2 ON
12 00 AGC OFF selection
01 AGC FAST selection
02 AGC MID selection
03 AGC SLOW selection
22 00 Noise blanker OFF
01 Noise blanker ON
32 00 Audio peak filter OFF
01 Audio peak filter WIDE ON
( 320 Hz is selected when SHARP
APF is set)
02 Audio peak filter MID ON
( 160 Hz is selected when SHARP
APF is set)
03 Audio peak filter NAR ON
( 80 Hz is selected when SHARP APF
is set)
40 00 Noise reduction OFF
01 Noise reduction ON
41 00 Auto notch function OFF
01 Auto notch function ON
42 00 Repeater tone OFF
01 Repeater tone ON
43 00 Tone squelch OFF
01 Tone squelch ON
44 00 Speech compressor OFF
01 Speech compressor ON
45 00 Monitor function OFF
01 Monitor function ON
Cmd. Sub Cmd. Data Description
16 46 00 VOXfunctionOFF
01 VOXfunctionON
47 00 BK-IN function OFF
01 Semi BK-IN function ON
02 Full BK-IN function ON
48 00 Manual notch function OFF
01 Manual notch function ON
4C 00 VSCfunctionOFF
01 VSCfunctionON
4D 00 AGCVRfunctionOFF
01 AGCVRfunctionON
4E 00 DIGI-SEL function OFF
01 DIGI-SEL function ON
4F 00 Twin peak filter OFF
01 Twin peak filter ON
50 00 Dial lock function OFF
01 Dial lock function ON
55 00 15 kHz roofing filter selection
01 6 kHz roofing filter selection
02 3 kHz roofing filter selection
56 00 SHARP selection for DSP filter type
01 SOFT selection for DSP filter type
57 00 WIDE selection for manual notch
width
01 MID selection for manual notch width
02 NAR selection for manual notch width
58 00 WIDE selection for SSB transmit
bandwidth
01 MID selection for SSB transmit band-
width
02 NAR selection for SSB transmit band-
width
17
see p. 14-12 Send CW messages*
1
18 00 Turn OFF the transceiver.
01 Turn ON the transceiver.*
2
19 00 Read the transceiver ID
1A 00
see p. 14-13 Send/read memory contents
01 see p. 14-10 Send/read band stacking register con-
tents
02
see p. 14-10 Send/read memory keyer contents
03 00 to 49 Send/read the selected filter width
( SSB, CW, PSK: 00=50 Hz to
40=3600 Hz; RTTY: 00=50 Hz to
31=2700 Hz; AM: 00=200 Hz to
49=10 kHz)
04 00 to 13 Send/read the selected AGC time
constant (00=OFF, 01=0.1/0.3 sec.,
13=6.0/8.0 sec.)
050001 00 to 10 Send/read SSB TX Tone (Bass) level
(00 =–5 to 10=+5)
050002 00 to 10 Send/read SSB TX Tone (Treble)
level (00=–5 to 10=+5)
050003 00 to 10 Send/read SSB RX Tone (Bass) level
(00 =–5 to 10=+5)
050004 00 to 10 Send/read SSB RX Tone (Treble)
level (00=–5 to 10=+5)
050005 00 to 10 Send/read AM TX Tone (Bass) level
(00 =–5 to 10=+5)
*
1
In the CW mode, if the [TRANSMIT] or an external TX switch is ON, or
the Break-in function is ON, a message will be transmitted as CW code
when you send it from your PC.
*
2
The power ON command (18 01) is available only when the trans-
ceiver is standby mode.
