Icom IC-7800 - Page 203

14-5
D Command table (continued)
14
CONTROL COMMAND
Cmd. Sub Cmd. Data Description
1A 050006 00 to 10 Send/read AM TX Tone (Treble) level
(00=–5 to 10=+5)
050007 00 to 10 Send/read AM RX Tone (Bass) level
(00 =–5 to 10=+5)
050008 00 to 10 Send/read AM RX Tone (Treble) level
(00=–5 to 10=+5)
050009 00 to 10 Send/read FM TX Tone (Bass) level
(00 =–5 to 10=+5)
050010 00 to 10 Send/read FM TX Tone (Treble) level
(00=–5 to 10=+5)
050011 00 to 10 Send/read FM RX Tone (Bass) level
(00 =–5 to 10=+5)
050012 00 to 10 Send/read FM RX Tone (Treble) level
(00=–5 to 10=+5)
050013
see p. 14-12 Send/read SSB TX bandwidth for wide
050014 see p. 14-12 Send/read SSB TX bandwidth for mid.
050015 see p. 14-12 Send/read SSB TX bandwidth for narrow
050016 0000 to
0255
Send/read speech level
(0000=0% to 0255=100%)
050017 0000 to
0255
Send/read CW side tone gain
(0000=0% to 0255=100%)
050018 00 or 01 Send/read CW side tone gain limit
(00=OFF, 01=ON)
050019 0000 to
0255
Send/read beep gain
(0000=min. to 0255=max.)
050020 00 or 01 Send/read beep gain limit
(00=OFF, 01=ON)
050021 0000 to
0255
Send/read headphones output ratio
(0000=0.60 to 0255=1.40)
050022 00 or 01 Send/read headphone output selection
(00=separated, 01=mixed)
050023 00 or 01 Send/read AF/SQL signal output to
ACC-A (00=Main; 01=Sub)
050024 00 or 01 Send/read AF/SQL signal output to
ACC-B (00=Main; 01=Sub)
050025 0000 to
0255
Send/read AF output level to ACC-A
(0000=0% to 0255=100%)
050026 0000 to
0255
Send/read AF output level to ACC-B
(0000=0% to 0255=100%)
050027 0000 to
0255
Send/read S/P DIF output level
(0000=0% to 0255=100%)
050028 0000 to
0255
Send/read MOD output level to ACC-
A (0000=0% to 0255=100%)
050029 0000 to
0255
Send/read MOD output level to ACC-
B (0000=0% to 0255=100%)
050030 0000 to
0255
Send/read S/P DIF MOD output level
(0000=0% to 0255=100%)
050031 00 to 08 Send/read MOD input connector dur-
ing DATA OFF
( 00=MIC; 01=ACC-A; 02=ACC-B;
03=MIC/ACC-A; 04=MIC/ACC-B;
05=ACC-A/ACC-B; 06=MIC/ACCA/
ACC-B; 07=S/P DIF, 08=LAN)
050032 00 to 08 Send/read MOD input connector dur-
ing DATA1
( 00=MIC; 01=ACC-A; 02=ACC-B;
03=MIC/ACC-A; 04=MIC/ACC-B;
05=ACC-A/ACC-B; 06=MIC/ACCA/
ACC-B; 07=S/P DIF, 08=LAN)
050033 00 to 08 Send/read MOD input connector dur-
ing DATA2
( 00=MIC; 01=ACC-A; 02=ACC-B;
03=MIC/ACC-A; 04=MIC/ACC-B;
05=ACC-A/ACC-B; 06=MIC/ACCA/
ACC-B; 07=S/P DIF, 08=LAN)
Cmd. Sub Cmd. Data Description
1A 050034 00 to 08 Send/read MOD input connector dur-
ing DATA3
( 00=MIC; 01=ACC-A; 02=ACC-B;
03=MIC/ACC-A; 04=MIC/ACC-B;
05=ACC-A/ACC-B; 06=MIC/ACCA/
ACC-B; 07=S/P DIF, 08=LAN)
050035 00 to 02 Send/read the band selection for oper-
ating frequency band signal output to
ACC-A (00=MAIN, 01=SUB, 02=TX)
050036 00 to 02 Send/read the band selection for oper-
ating frequency band signal output to
ACC-A (00=MAIN, 01=SUB, 02=TX)
050037 00 or 01 Send/read relay type selection
(00=Lead, 01=MOS-FET)
050038 00 to 07 Send/read main band’s external meter
output selection
( 00=Auto, 01=S (main), 02=Po,
03=SWR, 04=ALC, 05=COMP,
06=VD,07=ID)
050039 00 to 07 Send/read sub band’s external meter
output selection
( 00=Auto, 01=S (sub), 02=Po,
03=SWR, 04=ALC, 05=COMP,
06=VD,07=ID)
050040 0000 to
0255
Send/read main band’s external meter
output level (0000=0% to 0255=100%)
050041 0000 to
0255
Send/read sub band’s external meter
output level (0000=0% to 0255=100%)
050042 00 to 02 Send/read reference signal in/out set-
ting (00=IN, 01=OFF, 02=OUT)
050043 0000 to
0255
Send/read reference signal frequency
setting (0000=0% to 0255=100%)
050044 0000 to
0255
Send/read LCD unit backlight bright-
ness (0000=0% to 0255=100%)
050045 0000 to
0255
Send/read switch indicator brightness
(0000=1 to 0255=100)
050046 00 to 02 Send/read screen image type
(00=A, 01=B, 02=C)
050047 00 to 03
04 to 06
07 to 09
10 to 13
14 to 17
Send/read frequency readout font
( 00=Italic (1), 01=Italic (2),
02=Italic (3), 03=Italic (4),
04=Round (1), 05=Round (2),
06=Round (3), 07=Shadow (1),
08=Shadow (2), 09=Shadow (3),
10=Qubic (1), 11=Qubic (2),
12=Qubic (3), 13=Qubic (4),
14=IC-780 (1), 15=IC-780 (2),
16=IC-780 (3), 17=IC-780 (4))
050048 00 or 01 Send/read font for other than fre-
quency readout (00=Normal, 01=Slim)
050049 00 to 02 Send/read meter type
(00=Standard, 01=Edgewise, 02=Bar)
050050 00 or 01 Send/read meter type during wide
screen or mini scope indication
(00=Edgewise, 01=Bar)
050051 00 or 01 Send/read peak hold set for Bar meter
(00=OFF, 01=ON)
050052 00 or 01 Send/read memory name indication
setting (00=OFF, 01=ON)
050053 00 or 01 Send/read audio peak filter width pop-
up indication setting
(00=OFF, 01=ON)
050054 00 or 01 Send/read manual notch width pop-up
indication setting (00=OFF, 01=ON)
050055 00 or 01 Send/read output signal setting for ex-
ternal display (00=OFF, 01=ON)
