Icom IC-7800 - Page 205

14-7
D Command table (continued)
14
CONTROL COMMAND
Cmd. Sub Cmd. Data Description
1A 050113
see p. 14-11 Send/read waveform color for max.
hold
050114 00 to 02 Send/read scope sweep speed for
±2.5 kHz span
(00=Slow, 01=Mid., 02=Fast)
050115 00 to 02 Send/read scope sweep speed for ±5
kHz span
(00=Slow, 01=Mid., 02=Fast)
050116 00 to 02 Send/read scope sweep speed for
±10 kHz span
(00=Slow, 01=Mid., 02=Fast)
050117 00 to 02 Send/read scope sweep speed for
±25 kHz span
(00=Slow, 01=Mid., 02=Fast)
050118 00 to 02 Send/read scope sweep speed for
±50 kHz span
(00=Slow, 01=Mid., 02=Fast)
050119 00 to 02 Send/read scope sweep speed for
±100 kHz span
(00=Slow, 01=Mid., 02=Fast)
050120 00 to 02 Send/read scope sweep speed for
±250 kHz span
(00=Slow, 01=Mid., 02=Fast)
050121
see p. 14-11 Send/read scope edge frequencies for
0.03 to 1.60 MHz band
050122
see p. 14-11 Send/read scope edge frequencies for
1.60 to 2.00 MHz band
050123
see p. 14-11 Send/read scope edge frequencies for
2.00 to 6.00 MHz band
050124
see p. 14-11 Send/read scope edge frequencies for
6.00 to 8.00 MHz band
050125
see p. 14-11 Send/read scope edge frequencies for
8.00 to 11.00 MHz band
050126
see p. 14-11 Send/read scope edge frequencies for
11.00 to 15.00 MHz band
050127
see p. 14-11 Send/read scope edge frequencies for
15.00 to 20.00 MHz band
050128
see p. 14-11 Send/read scope edge frequencies for
20.00 to 22.00 MHz band
050129
see p. 14-11 Send/read scope edge frequencies for
22.00 to 26.00 MHz band
050130
see p. 14-11 Send/read scope edge frequencies for
26.00 to 30.00 MHz band
050131
see p. 14-11 Send/read scope edge frequencies for
30.00 to 45.00 MHz band
050132
see p. 14-11 Send/read scope edge frequencies for
45.00 to 60.00 MHz band
050133 00 or 01 Send/read auto voice monitor set
(00=OFF, 01=ON)
050134 03 to 10 Send/read voice memory short play
time (03=3 sec. to 10=10 sec.)
050135 05 to 30 Send/read voice memory normal re-
cord time (05= 5 sec. to 30=30 sec.)
050136 00 Normal selection for contest num-
ber style
01
“190→ANO” selection for contest
number style
02
“190→ANT” selection for contest
number style
03
“90→NO” selection for contest num-
ber style
04
“90→NT” selection for contest num-
ber style
050137 01 to 04 Send/read count up trigger channel
(01=M1, 02=M2, 03=M3, 04=M4)
050138 0001 to
9999
Send/read present number
(0001=1, 9999=9999)
Cmd. Sub Cmd. Data Description
1A 050139 01 to 60 Send/read CW keyer repeat time
(01=1 sec. to 60=60 sec.)
050140 28 to 45 Send/read CW keyer dot/dash ratio
(28=1:1:2.8 to 45=1:1:4.5)
050141 00 to 03 Send/read rise time
( 00=2 msec., 01=4 msec., 02=6 msec.,
03=8 msec.)
050142 00 or 01 Send/read paddle polarity
(00=Normal, 01=Reverse)
050143 00 to 02 Send/read keyer type (00=Straight,
01=Bug-key, 02=ELEC-Key)
050144 00 or 01 Send/read mic. up/down keyer set
(00=OFF, 01=ON)
050145 00 or 01 Send/read RTTY decode USOS
(00=OFF, 01=ON)
050146 00 or 01 Send/read RTTY decode new line
code (00=CR,LF,CR+LF, 01=CR+LF)
050147 00 to 02 Send/read RTTY diddle (00=OFF,
01=Blank, 02=LTRS (Letter code))
050148 00 or 01 Send/read RTTY TX USOS
(00=OFF, 01=ON)
050149 00 or 01 Send/read RTTY auto CR+LF by TX
(00=OFF, 01=ON)
050150 00 or 01 Send/read RTTY time stamp set
(00=OFF, 01=ON)
050151 00 or 01 Send/read clock selection for time
stamp (0=Local time, 1=CLOCK2)
050152 00 or 01 Send/read frequency stamp
(00=OFF, 01=ON)
050153
see p. 14-11 Send/read received text font color
050154
see p. 14-11 Send/read transmitted text font color
050155
see p. 14-11 Send/read time stamp text font color
050156
see p. 14-11 Send/read text font color in TX buffer
050157 00 or 01 Send/read PSK time stamp set
(00=OFF, 01=ON)
050158 00 or 01 Send/read clock selection for time
stamp (00=Local time, 01=Clock 2)
050159 00 or 01 Send/read frequency stamp
(00=OFF, 01=ON)
050160
see p. 14-11 Send/read received text font color for
PSK decoder
050161
see p. 14-11 Send/read transmitted text font color
(PSK)
050162
see p. 14-11 Send/read time stamp text font color
(PSK)
050163
see p. 14-11 Send/read text font color in TX buffer
(PSK)
050164 00 or 01 Send/read scan speed
(00=Low, 01=High)
050165 00 or 01 Send/read scan resume
(00=OFF, 01=ON)
050166
see p. 14-12 Send/read antenna selection for 0.03
to 1.60 MHz band
050167
see p. 14-12 Send/read antenna selection for 1.60
to 2.00 MHz band
050168
see p. 14-12 Send/read antenna selection for 2.00
to 6.00 MHz band
050169
see p. 14-12 Send/read antenna selection for 6.00
to 8.00 MHz band
050170
see p. 14-12 Send/read antenna selection for 8.00
to 11.00 MHz band
050171
see p. 14-12 Send/read antenna selection for 11.00
to 15.00 MHz band
050172
see p. 14-12 Send/read antenna selection for 15.00
to 20.00 MHz band
050173
see p. 14-12 Send/read antenna selection for 20.00
to 22.00 MHz band
