Icom ID-5100A

12
MENU SCREEN
12-23
Altitude (Default:OFF)
GPS > GPS TX Mode > D-PRS > TX Format > Position
> Altitude
Select whether or not to transmit the altitude data in ad-
dition to the position data in the D-PRS mode.
• OFF: No altitude data is transmitted.
• ON: Transmits altitude data in addition to position
data.
The number of enterable characters on “Comment”
differ, depending on the “Data Extension” and
“Altitude” settings.
DataExtension (Default:OFF)
GPS > GPS TX Mode > D-PRS > TX Format > Position
> Data Extension
Select whether or not to transmit the course and speed
data or Power/Height/Gain/Directivity data in addition
to the position data in the D-PRS mode.
• OFF: Transmits only the position data.
• Course/Speed: Transmits the course and speed data
in addition to the position data.
The course and speed data will not
be transmitted when your position is
manually set.
When transmitting with this setting,
your station is regarded as a vehicle
station.
• Power/Height/Gain/Directivity:
Transmits the programmed Power,
Height, Gain, and Directivity data in
addition to the position data when
your position is manually set.
When transmitting with this setting,
your station is regarded as a base
station.
Icom transceivers (IC-7100, ID-51A/E,
ID-31A/E, IC-9100, IC-80AD/E80D,
ID-880H/E880, IC-92AD/E92D, IC-
2820H/E2820, ID-800H, IC-91AD/IC-
E91, IC-U82, IC-V82) cannot receive
signals with this setting, so they can-
not receive Power, Height, Gain and
Directivity data.
The number of characters you can enter in “Comment”
differs, depending on the “Data Extension” and
“Altitude” settings.
Power (Default:0W)
GPS > GPS TX Mode > D-PRS > TX Format > Position
> Power
Select the TX power level of the base station, to trans-
mit in addition to the position data.
Select between 0, 1, 4, 9, 16, 25, 36, 49, 64, and 81W.
When the “Data Extension” item is set to “Power/
Height/Gain/Directivity,” this item appears.
Height (Default:10ft)
GPS > GPS TX Mode > D-PRS > TX Format > Position
> Height
Select the height of the base station’s antenna, to trans-
mit in addition to the position data.
Select between 10, 20, 40, 80, 160, 320, 640, 1280,
2560, and 5120 feet.*
* If the Altitude/Distance unit is set to “m,” select between 3, 6,
12, 24, 49, 98, 195, 390, 780, and 1561 meters.
When the “Data Extension” item is set to “Power/
Height/Gain/Directivity,” this item appears.
Gain (Default:0dB)
GPS > GPS TX Mode > D-PRS > TX Format > Position
> Gain
Select the gain of the base station’s antenna, to trans-
mit in addition to the position data.
Select between 0 and 9 dB.
When the “Data Extension” item is set to “Power/
Height/Gain/Directivity,” this item appears.
Directivity (Default:Omni)
GPS > GPS TX Mode > D-PRS > TX Format > Position
> Directivity
Select the direction the base station’s antenna was
pointing, to transmit in addition to the position data.
Select between Omni, 45ºNE, 90ºE, 135ºSE, 180ºS,
225ºSW, 270ºW, 315ºNW and 360ºN.
When the “Data Extension” item is set to “Power/
Height/Gain/Directivity,” this item appears.
GPS items (Continued)
