Icom ID-5100A Full Manual

12
MENU SCREEN
12-54
Function Description
RemoteMICKey Up/DownMICKey
[F-1] [F-2] [UP] [DN]
TONE/DSQL
Push to toggle between tone types.
<<MODE>> FM/FM-N
“TONE” (Repeater Tone)
“TSQLS” (Pocket Beep with Tone Squelch)
“TSQL” (Tone Squelch)
“DTCSS” (Pocket Beep with DTCS Code Squelch)
“DTCS” (DTCS Code Squelch)
“TSQL-R” (Reverse Tone Squelch)
“DTCS-R” (Reverse DTCS Code Squelch)
<<MODE>> DV
* This can be also set in the DR screen.
“DSQLS” (Pocket Beep with Digital Call sign Squelch)
“DSQL” (Digital Call sign Squelch)
“CSQLS” (Pocket Beep with Digital Code Squelch)
“CSQL” (Digital Code Squelch)
   
MW
In the VFO mode or in the DR screen, hold down to save the fre-
quency displayed in the MAIN band into a Memory channel.
• The frequency is automatically saved in a blank channel.
   
MUTE Push to turn the Mute function ON or OFF.
   
Voice TX (T1)
Push to transmit the voice audio recorded on the SD card once.
Hold down for 1 second to repeatedly transmit the voice audio.
• This key function can also be used in the DR screen.
If the voice audio is not stored in the [T1] (Voice memory number
for TX) in the Voice TX record screen, this function is invalid.
   
DTMF
DIRECT TX
Push to display the DTMF code direct entry mode screen.
 
N/A N/A
T-CALL Push to transmit a 1750 Hz tone.
   
•DuringTX:
●: Default setting : Available N/A: Not available
Function Description
--- No function

● ● ●
LOW Push to change the transmit power level.
   
Voice TX
Push to transmit the voice audio recorded on the SD card once.
Hold down for 1 second to repeatedly transmit the voice audio.
- To make a repeat transmission, [PTT] must be released.
   
T-CALL Push to transmit a 1750 Hz tone.
●
  
Function items (Continued)
• During RX/Standby (Continued):
●: Default setting : Available N/A: Not available
