Icom ID-5100A

13
OTHER FUNCTIONS
13-18
•Receivefrequencysetting
Command: 00, 03, 05
q
0XXXX
we
X
rt
XX 40
10H zdigit：0, 3, 5, 6 (according to the 100 Hz digit)
1 Hz digit：0 (Fixed) 1 kHz digit：0, 1, 2, 3, 5, 6, 7, 8 100 Hz digit：0, 2, 3, 5, 6, 7 100 kHz digit：0−9 10 kHz digit：0−9 10 MHz digit：0−9 1 MHz digit：0−9 1000 MHz digit：0 (Fixed) 100 MHz digit： 1, 3, 4, 5
100Hzdigit 10Hzdigit
0 0
2 5
3 3
5 0
6 6
7 5
• Operatingmode
Command:01, 04, 06
q
XXXX
w
Operatingmode
q Mode wFiltersetting
AM 02 01
AM-N 02 02
FM 05 01
FM-N 05 02
DV 17 01
•DuplexFrequencyoffsetsetting
Command: 0C, 0D
qew
XX
XXXX
100 Hz digit
100 kHz digit
10 kHz digit
10 MHz digit
1 kHz digit
1 MHz digit
•RFpowerlevelsetting
Command: 14 0A
LOW MID HIGH
0000–0026 0027–0127 0128–0255
•Externalmicrophonegainsetting
Command: 14 0B
1 2 3 4
0000–0063 0064–0127 0128–0191 0192–0255
•VOXgainsetting
Command: 14 16
OFF 1 2 3 4
0000–0022 0023–0046 0047–0069 0070–0092 0093–0115
5 6 7 8 9
0016–0139 0140–0162 0163–0185 0186–0208 0209–0232
10
0233–0255
•Repeatertone/tonesquelchfrequencysetting
Command: 1B 00, 1B 01
q* ew
00
XXXX
Fixed: 0 Fixed: 0 100 Hz digit 10 Hz digit 1 Hz digit 0.1 Hz digit
*Not necessary when setting a frequency.
•DTCScodeandpolaritysetting
Command: 1B 02
XX0XXX
q* we
0 (fixed) First digit: 0–7 Second digit: 0–7 Third digit: 0–7
Receive polarity: 0: Normal
1: Reverse
Transmit polarity: 0: Normal
1: Reverse
•Digitalcodesquelchsetting
Command: 1B 07
XX
q
First digit: 0–9 Second digit: 0–9
•DVMYcallsignsetting
Command: 1F 00
Set your own call sign and note of up to 12 charac-
ters.
XX XXXXXXXXXX
o–!2q–i
• • •
q–i: Your own call sign setting (8 characters)
o–!2: Note setting (4 characters)
Remote jack (CI-V) information (Continued)
