Icom ID-5100A

13
OTHER FUNCTIONS
13-21
Remote jack (CI-V) information (Continued)
•GPS/D-PRSdata—Object
Command: 20 0301, 20 0302
XX01 XXX XX XXX XXXX
!2–!6!0
Data number
!1 @7 @8q–o
• • •
XXX XXXXX
• • •• • •
XXXX
!7–@2 @3–@6 #9 $0 $1
$2 %2
XXX XXXXX
• • •
#2–#8
• • •
XXX X XXXX
$3–%1
• • •
XXXX
@9–#1
• • •
q–o: Call sign/SSID
*9 ASCII characters (A–Z, 0–9, /, -, space)
!0, !1: Symbol
*2 ASCII characters (00h–EFh)
!2–!6: Latitude (ddºmm.mmm format)
!7–@2: Longitude (dddºmm.mmm format)
@3–@6: Altitude (0.1 meter steps)
@7, @8: Course (1 degree steps)
@9–#1: Speed (0.1 km/h steps)
#2–#8: Date (UTC: yyyymmddHHMMSS)
* y: Year, m: Month, d: Day, H: Hour, M: Minute,
S: Second
#9: Power (see the table to the right)
$0: Height (see the table to the right)
$1: Gain (see the table to the right)
$2: Directivity (see the table to the right)
Power Height Gain Directivity
Data (W) (m/ft) (dB) (deg)
0 0 3/10 0 Omni-direction
1 1 6/20 1 45º NE
2 4 12/40 2 90º E
3 9 24/80 3 135º SE
4 16 49/160 4 180º S
5 25 98/320 5 225º SW
6 36 195/640 6 270º W
7 49 390/1280 7 315º NW
8 64 780/2560 8 360º N
9 81 1561/5120 9 —
$3–%1: Name
*9 ASCII characters (00h–EFh)
%2: Type (1=Live, 0=Killed)
•GPS/D-PRSdata—Item
Command: 20 0301, 20 0302
XX02 XXX XX XXX XXXX
!2–!6!0
Data number
!1 @7 @8q–o
• • •
XXX XXXXX
• • •• • •
XXXX
!7–@2 @3–@6 #2 #3 #4
#5 $5
XXX XXXXX
• • •
XXX X XXXX
#6–$4
• • •
@9–#1
• • •
q–o: Call sign/SSID
*9 ASCII characters (A–Z, 0–9, /, -, space)
!0, !1: Symbol
*2 ASCII characters (00h–EFh)
!2–!6: Latitude (ddºmm.mmm format)
!7–@2: Longitude (dddºmm.mmm format)
@3–@6: Altitude (0.1 meter steps)
@7, @8: Course (1 degree steps)
@9–#1: Speed (0.1 km/h steps)
#2: Power (see the table to the right)
#3: Height (see the table to the right)
#4: Gain (see the table to the right)
#5: Directivity (see the table to the right)
Power Height Gain Directivity
Data (W) (m/ft) (dB) (deg)
0 0 3/10 0 Omni-direction
1 1 6/20 1 45º NE
2 4 12/40 2 90º E
3 9 24/80 3 135º SE
4 16 49/160 4 180º S
5 25 98/320 5 225º SW
6 36 195/640 6 270º W
7 49 390/1280 7 315º NW
8 64 780/2560 8 360º N
9 81 1561/5120 9 —
#6–$4: Name
*9 ASCII characters (00h–EFh)
$5: Type (1=Live, 0=Killed)
