Valves
PIN FUNCTION
1 Air Assist Valve Control J8
2 0 V
1 Tamp Valve Control J9
2 0 V
1 Jet Valve Control J10
2 0 V
1 Vacuum Valve Control J11
2 0 V
Fan, blow-off module J7
PIN FUNCTION
1 +24 VDC
2 0 V
Rewind Motor “RR” J14
PIN FUNCTION
1 Motor Control
2 0 V
