ID Technology 250 - Printer; Applicator Interface Cable Pin Mapping

Model 250
Printer Applicator
Operators/Technical Manual Section Six
Section 6 Page 8 of 20
Printer / Applicator Interface Cable Pin Mapping
Model 250 “Printer” Connector 15 Pin “D” Connector 62501 Zebra “PAX” Series Printer DataMax “A Class” Series Printer 15 Pin “D” Connector 62502 Sato “S” Series Printer Datamax “PE” Series Printer 9 Pin “D” Connector 62503 Sato “Se” Series Printer 14 Pin Centronics Connector
FUNCTION PIN PIN PIN PIN
0 V 1 1 9 2
5 VDC 2 2 1 13
Print enable 3 3 5 5
Feed 4 4
Pause 5 5
Reprint 6 6 4 7
N/C 7 7
N/C 8 8
Low ribbon 9 9 2 10
Service
Required
10 10,14 3 4
Print end 11 11 6 6
Label out 12 12 7 1
Ribbon out 13 13 8 3
Online 14 9 *
N/C 15 15
*
Sato “Se” series printers require “Ext Pin 9” configured to Mode 2. Consult printer
manual “Service Mode Configuration” section for setup procedure.
