Model 250
Printer Applicator
Operators/Technical Manual Section One
Section 1 Page 1 of 5
Section One
General Specifications
1.1 Standard Features:
♦ Choice of printer units to suit every application. The 250 Applicator will
accommodate standard Sato, Zebra & Datamax print engines without
modification.
♦ Microprocessor-driven on a single board
♦ 4” Tamp stroke standard, capable of conversion to various stroke
lengths from 2’ to 12”
♦ 8” diameter maximum rewind roll capacity (approximately 1500’ of
standard 40# liner)
♦ Regulators and air gauges controlling Tamp, Air Assist and Vacuum
Pressures
♦ Right and Left Hand options
1.2 Overall Dimensions
Figure 2-1 Dimensions Front View Figure 2-2 Dimensions Side View
