Model 250
Printer Applicator
Operators/Technical Manual Section Six
Section 6 Page 5 of 20
Pins Outs of the 250 Applicator
Beacon 9 pin Female D Connector
PIN FUNCTION
2 Red Beacon
6 +24 VDC
7 Amber Beacon
8 Green Beacon
1
3 Signal Duplication of Product Detect Pin
4
5 0 V Duplication of Product Detect Pin
9
Product detect 9 pin Female D Connector
PIN FUNCTION
3 Signal
5 0 V
Short to 0 V to trigger applicator. NPN
(sinking) or relay contact recommended.
6 +24 VDC
1
2 Red Beacon Duplication of Beacon Pin
4
7 Amber Beacon Duplication of Beacon Pin
8 Green Beacon Duplication of Beacon Pin
9
Low Label Detect J17
PIN FUNCTION
1 +24 VDC
2 Signal (sink)
3 Reserved
4 0 V
Smart Tamp J6
PIN FUNCTION
1 +24 VDC
2 Signal (sink)
3 Signal (sink)
4 0 V
