MODEL 250 IDT BOM (STD MACHINE) MANUAL VERSION
LEVEL 1 LEVEL 2 LEVEL 3 LEVEL 4
ITEM QTY ITEM QTY ITEM QTY ITEM QTY PART NO DESCRIPTION
BASE MODULE
11 62000 ASSY BASE MODULE
U-ARM ASSEMBLY
11 62001 UNIVERSAL BRACKET
1 2 SHCS M5 X 12 S/S
2 2 PLAIN WASHER M5 S/S
BASE PLATE ASSEMBLY
21 62009 ASSY. BASE PLATE
1 1 62010 BASE PLATE
2 2 62011 BASE PLATE BRKT
3 4 SHCS M6 X 45 S/S
44
5 2 HEX CAP SCR M20 X 50 S/S
6 2 LOCK WASHER M20
7 2 PLAIN WASHER M20 S/S
1 1 62030-08 IDLER ROLL
2 1 62031 IDLER SHAFT
3 1 62034 ROLL SPACER
4 1 M6 X 10 PAN HD PH S/S
5 1 WASHER PLAIN M-6 S/S
6 1 SHCS M6 X 35 S/S
7 2 62015-08 ASSY SPRING COLLAR - 1"
8 1 62030-16 IDLER ROLL
9 1 62031 IDLER SHAFT
10 1 62034 ROLL SPACER
11 1 M6 X 10 PAN HD PH S/S
12 1 WASHER PLAIN M-6 S/S
13 1 62017 COVER STANDOFF
8 1 62016 COVER
9 1 6010 ELECTRICAL SHOCK CAUTION LABEL
10 1 5134a ELECTROSTATIC SENSITIVE DEVICES
11 1 62012 NAMEPLATE LABEL
12 3 SHCS M4 X 10 S/S
13 10 ft. TIUBO7B-33 TUBING URETHANE 1/4"
14 4 ft. TUO805B-33 TUBING URETHANE 5/16"
15 1 NAW2000-N02-BG-C FILTER/REGULATOR/GUAGE
16 1 MALE CONNECTOR
17 1 10-3 1/4 NPT AIR HOSE FITTING
18 1 62180 AIR ASSIST TUBE
19 1 62181 AIR ASSIST BBRACKET
UNWIND ASSEMBLY
31 62020-12 ASSY UNWIND
1 1 62021 UNWIND BLOCK
2 1 62022 UNWIND SHAFT
3 1 62030-08 IDLER ROLL
4 1 62031 IDLER SHAFT
5 1 M6 X 10 PAN HD PH S/S
6 1 WASHER PLAIN M-6 S/S
7 2 62029 6004.2RSR.C3 (FAG)
8 2 62032 BEARING PLANE FLANGED SINTERED BRONZE .5"
9 1 62024 BRAKE BAND
10 1 SPRING CLIP EXT .781"
11 2 62025 SHAFT COLLAR
12 1 62026 DANCER SHAFT
13 1 DRIVE PIN 1/4" X 2"
14 1 62027 SPRING ANCHOR PIN
15 2 WASHER PLAIN M-6 S/S
16 2 MACH SCREW PAN HD PH M-6 X 6 S/S
17 1 62028 SPRING
18 1 SPRING ANCHOR PIN 1/4" X 2.5"
19 2 SHCS M6 X 60 S/S
20 2 SPRING CLIP EXT .50"
21 2 FLAT HEAD SOC CAP SCR M6 X 20 S/S
22 2 M6 X 6 SET SCREW S/S
23 2 62006-12 UNWIND DISK - 12.5"
24 2 62006-16 UNWIND DISK - 16.5"
UNWIND HUB ASSEMBLY
41 62004-12 ASSY UNWIND HUB - 12" CAPACITY
1 3 62005 UNWIND HUB
2 2 62006-12 UNWIND DISK - 12.5"
3 1 62007 UNWIND HUB DECAL
4 1 62023-12 DANCER ARM
5 1 62052-12 REWIND DISK
6 9 SHCS M4 X 10 S/S
7 1 SOC SET SCREW M8 X 12 SOFT TIP S/S
8 3 SOC SET SCREW M8 X 12 S/S
REWIND ASSEMBLY
51 62050 REWIND ASSY.
1 4 62056 TEE NUT M4
Model 250 Standard Machine
Page 1
To Next Page
