ID Technology 250 - Base Module Assembly

Model 250
BASE MODULE
ASSEMBLY
62000
REV
.00 ± .02
.000 ± .005
ANGLES ± 2°
DWG NOSHEET #SIZE
DESCRIPTION
1 of 2
THE INFORMATION CONTAINED IN THIS DRAWING IS THE SOLE
PROPERTY OF I D TECHNOLOGY, CORP. ANY REPRODUCTION IN PART OR
WHOLE WITHOUT THE WRITTEN PERMISSION OF I D TECHNOLOGY IS PROHIBITED.
6
5
2
ITEM QTY ITEM QTY ITEM QTY ITEM QTY PART NO DESCRIPTION
BASE MODULE
1 1
62000 ASSY BASE MODULE (RH)
U-ARM ASSEMBLY
1
1
62001 UNIVERSAL BRACKET
BASE PLATE ASSEMBLY
2
1
62009 ASSY. BASE PLATE
UNWIND ASSEMBLY
3
1
62020-12 ASSY UNWIND
REWIND ASSEMBLY
4
1
62050 REWIND ASSY.
PNEUMATICS ASSEMBLY
5
1
62100 ASSY PNEUMATICS STD TAMP
ELECTRONICS ASSEMBLY
6 1 62500 ELECTRONIC MODULE
