ID Technology 250 - 15 Pin Female D Connector

Model 250
Printer Applicator
Operators/Technical Manual Section Six
Section 6 Page 6 of 20
Tamp Home J5
PIN FUNCTION
1 +24 VDC
2 Signal (sink)
3 Signal (sink)
4 0 V
Auxiliary Input J4
PIN FUNCTION
1 +24 V
2 Signal (sink)
3 Signal (sink)
4 0 V
Printer Interface
PIN FUNCTION
15 pin Female D Connector
1 0 V From printer
2 5 VDC From printer
3 Print enable To printer
4 Feed To printer
5 Pause To printer
6 Reprint To printer
7 N/C
8 N/C
9 Low ribbon From printer
10 Service Required From printer
11 Print end From printer Logic High when Printing, Low when idle.
-Sato “External Signal” Type 4
-Zebra “Applicator Port” Mode 2
12 Label out From printer
13 Ribbon out From printer
14 Data ready From printer
15 N/C
