ID Technology 250 - Tamp-Jet Module Parts Identification

Model 250
Printer Applicator
Operators/Technical Manual Section 3A
Section 3A Page 2 of 9
Figure 3A-2 Tamp-Jet Module
Parts Identification
Table 3A-2 Tamp-Jet Module Parts Identification
No. Qty Nomenclature
1 1 Male Run Tee – unifit
2 1 Nipple
3 1 Reducer, One – Touch
3 1 2-Way D.O. Valve
5 1 Reducer – One Touch
6 1 Reducer Nipple 5/16” – ¼”
7 1 Union Tee
