ID Technology 250 - Page 118

BASE MODULE
ASSEMBLY
62000
REV
.00 ± .02
.000 ± .005
ANGLES ± 2°
Model 250
DESCRIPTION
SIZE DWG NO
2 of 2
SHEET #
THE INFORMATION CONTAINED IN THIS DRAWING IS THE SOLE
PROPERTY OF I D TECHNOLOGY, CORP. ANY REPRODUCTION IN PART OR
WHOLE WITHOUT THE WRITTEN PERMISSION OF I D TECHNOLOGY IS PROHIBITED.
3
4
1
ITEM QTY ITEM QTY ITEM QTY ITEM QTY PART NO DESCRIPTION
BASE MODULE
1 1 62000 ASSY BASE MODULE (RH)
U-ARM ASSEMBLY
1 1 62001 UNIVERSAL BRACKET
BASE PLATE ASSEMBLY
2
1
62009 ASSY. BASE PLATE
UNWIND ASSEMBLY
3 1 62020-12 ASSY UNWIND
REWIND ASSEMBLY
4 1 62050 REWIND ASSY.
PNEUMATICS ASSEMBLY
5 1 62100 ASSY PNEUMATICS STD TAMP
ELECTRONICS ASSEMBLY
6
1
62500 ELECTRONIC MODULE
