AFL-xxx-9103 Panel PC
Page 134
Figure 6-23: Access Startup Folder
Step 5:
Click
N
EXT
to begin the touch panel driver inst
allation process (
Figure
6-23).
Step 6:
The license a
greement appears (
Figure 6-24
).
Figure 6-24: Start Touch Panel Driv
er Installation
