AFL-xxx-9103 Panel PC
Page 28
PIN DESCRIPTION
9 GND
Table 2-1: Touch Screen Connector
2.11.2 GPIO Connector
CN Label: JP3
CN Type:
10-pin connector
CN Location:
See
Figure 2-9
CN Pinouts:
See
Table 2-2
The GPIO connector is connected to external devices and can be programmed for
external machine control. As standard, the GPIO connector is not used in the
AFL-xxx-9103, but is still functional.
PIN DESCRIPTION PIN DESCRIPTION
1 GND 2 VCC5
3 GPO0 4 GPO1
5 GPO2 6 GPO3
7 GPI0 8 GPI1
9 GPI2 10 GPI3
Table 2-2: GPIO Connector
2.11.3 Front Panel Connectors
CN Label: JP2
CN Type:
8-pin connector
CN Location:
See
Figure 2-9
CN Pinouts:
See
Table 2-3
The front panel connectors connect to the buttons and indicators on the front panel. These
include the power and reset buttons, and the hard drive and power LEDs.
