IEI Technology AFL-xxx-9103 User Manual

AFL-xxx-9103 Panel PC
Page 40
PIN DESCRIPTION PIN DESCRIPTION
23 LVDS3+ 24 LVDS3-
25 GND 26 GND
27 VCCLCD 28 VCCLCD
29 VCCLCD 30 VCCLCD
Table 2-20: LVDS Connector
2.11.21 USB Connectors (Internal)
CN Label: USB3
CN Type:
8-pin header
CN Location:
See
Figure 2-9
CN Pinouts:
See
Table 2-21
The USB connectors connect to USB devices.
PIN DESCRIPTION PIN DESCRIPTION
1 USBVCC0 5 GND
2 D0F- 6 D1F+
3 D0F+ 7 D1F-
4 GND 8 USBVCC0
Table 2-21: USB Connectors
