AFL-xxx-9103 Panel PC
Page 9
1 x DDR2 memory module
1 x AT/ATX switch
1 x HSDPA module (optional)
The technical specifications for some of these components and the system are shown in
the sections below.
1.4.2 System Specifications
The technical specifications for the AFL-xxx-9103 are listed in Table 1-2.
SPECIFICATION AFL-10A-9103-R10 AFL-12B-9103-R10
Front Panel ABS/PC plastic front panel
Chassis Aluminum chassis
LCD Panel 10.4” 12.1”
Resolution 800 x 600 1024 x 768
Brightness (cd/m
2
) 400 400
Contrast Ratio 500:1 500:1
Viewing Angle (H-V) 120/100 160/160
Backlight MTBF 50000 50000
Touch Screen 5-wire resistive type
SSD CompactFlash®
Audio AMP 1.5 W + AMP 1.5 W (internal speaker)
Extension 1 x PCIe Mini (for wireless LAN module)
1 x Bluetooth module (USB interface, Bluetooth v2.0)
HSDPA Module Optional
I/O 1 x Audio out
4 x USB 2.0 ports
1 x Power switch
1 x Power input
1 x External SATA port
1 x RS-232 serial port
1 x RS-232/422/485 serial port
1 x Gigabit Ethernet port
1 x Reset button
