AFL-xxx-9103 Panel PC
Page 43
3.3 Installation and Configuration Steps
The following installation steps must be followed.
Step 1: Unpack the flat panel PC
Step 2: Install CompactFlash® card
Step 3: Install HDD
Step 4: Mount the flat panel PC
Step 5: Connect peripheral devices to the bottom panel of the flat panel PC
Step 6: Configure the systemStep 0:
3.4 Unpacking
To unpack the flat panel PC, follow the steps below:
WARNING!
The front side LCD screen has a protective plastic cover stuck to the
screen. Only remove the plastic cover after the flat panel PC has been
properly installed. This ensures the screen is protected during the
installation process.
Step 1: Use box cutters, a knife or a sharp pair of scissors to cut the seals of the outer
box.
Step 2: Open the outer box.
Step 3: Open the inner box.
Step 4: Lift the monitor out of the boxes.
Step 5: Remove both foam ends, one from each side.
Step 6: Pull the plastic cover off the flat panel PC.
