IEI Technology AFL-xxx-9103 User Manual

AFL-xxx-9103 Panel PC
Page 29
PIN DESCRIPTION PIN DESCRIPTION
1 POWER_LED_G 2 HDD_POWER
3 GND 4 HDD_LED-
5 POWER_LED_O 6 GND
7 PS_ON 8 GND
Table 2-3: Front Panel Connectors
2.11.4 Keypad Connector
CN Label: JP16
CN Type:
10-pin connector
CN Location:
See
Figure 2-9
CN Pinouts:
See
Table 2-4
The keypad connector connects to a numeric keypad for access control systems.
PIN DESCRIPTION PIN DESCRIPTION
1 MCLR 2 VOL+
3 +5 V 4 VOL-
5 GND 6 BRIGHT+
7 ICSPCLK 8 BRIGHT-
9 ICSPDAT 10 LCD ON_OFF
Table 2-4: Front Panel Connectors
2.11.5 PCIe Mini Connector
CN Label: MINI-PCIE1
CN Type:
10-pin connector
CN Location:
See
Figure 2-9
CN Pinouts:
See
Table 2-5
The keypad connector connects to a numeric keypad for access control systems.
