AFL-xxx-9103 Panel PC
Page 11
Specification AFLMB-9103GME
Touch Screen Controller DMC9000
Power Supply DC 12 V In
Dimensions 102 mm x 186 mm
Table 1-3: Motherboard Specifications
1.4.4 Flat Panel Screen Specifications
The AFL-xxx-9103 series come with a TFT LCD monitor at the front of the flat panel PC
(see
Figure 1-2). The specifications for the LCD monitor are shown below.
1.4.4.1 AFL-10A-9103-R10
SPECIFICATION AFL-10A-9103-R10
Model Toshiba LTA104D182F
Size 10.4”
Resolution 800 x 600
Active Area (mm) 211.2 x 158.4
Pixel Pitch (mm) 0.264 x 0.264
LCD Color 262K
View Angel (H/V) 120/100
Brightness (cd/m
2
) 400
Contrast Ratio 500:1
Supply Voltage (V) 3.3 V
Backlight 2 CCFL
Backlight MTBF (hrs.) 50000
Dimensions (WxHxD)(mm) 242 x 178.45 x 13.2
Table 1-4: AFL-10A-9103-R10 TFT LCD Monitor Specifications
1.4.4.2 AFL-12B-9103-R10
SPECIFICATION AFL-12B-9103-R10
Model Toshiba LTA121C50F
Size 12.1”
