IEI Technology AFL-xxx-9103 User Manual

AFL-xxx-9103 Panel PC
Page 37
PIN DESCRIPTION
10 GND
11 GND
Table 2-15: SATA1 Connector
2.11.16 SATA Ports
CN Label: SATA2
CN Type:
SATA connector
CN Location:
See
Figure 2-9
CN Pinouts:
See
Table 2-16
The SATA connectors connect to SATA hard drives and SATA CD-ROMs.
PIN DESCRIPTION
1 GND
2 TX+
3 TX-
4 GND
5 RX-
6 RX+
7 GND
8 GND
9 GND
Table 2-16: SATA Connector
2.11.17 PS/2 Keyboard & Mouse Connector
CN Label: KB/PS1
CN Type:
6-pin box header
CN Location:
See
Figure 2-9
CN Pinouts:
See
Table 2-17
