PIN DESCRIPTION
3 GND
Table 2-12: 12 V Power Connector
2.11.13 COM3 RS-232/422/485 Serial Port Connector
CN Label: COM3
CN Type:
DB-9 male
CN Location:
See
Figure 2-9
CN Pinouts:
See
Table 2-13
The COM3 serial port connector provides an RS-232, RS-422 or RS-485 data connection
to an attached device.
PIN RS-232 mode RS-422 mode RS-485 mode
1 DCD3 TX- D-
2 RX3 TX+ D+
3 TX3
4 DTR3
5 GND
6 DSR3 RX-
7 RTS3 RX+
8 CTS3
9 RI3
Table 2-13: COM3 Serial Port Connector
2.11.14 COM1 RS-232 Serial Port Connector
CN Label: COM1
CN Type:
DB-9 male
CN Location:
See
Figure 2-9
CN Pinouts:
See
Table 2-14
