IEI Technology AFL-xxx-9103 User Manual

AFL-xxx-9103 Panel PC
Page 33
PIN DESCRIPTION PIN DESCRIPTION
6 DATA 7 31 DATA 15
7 HDC_CS1# 32 HDC_CS3#
8 N/C 33 N/C
9 GROUND 34 IOR#
10 N/C 35 IOW#
11 N/C 36 VCC5
12 N/C 37 IRQ15
13 VCC_COM 38 VCC5
14 N/C 39 CSEL
15 N/C 40 N/C
16 N/C 41 HDD_RESET
17 N/C 42 IORDY
18 PA2 43 PDREQ
19 PA1 44 PDACK#
20 PA0 45 NC
21 DATA 0 46 66DET
22 DATA 1 47 DATA 8
23 DATA 2 48 DATA 9
24 N/C 49 DATA 10
25 VCC-IN CHECK2 50 GROUND
Table 2-9: CompactFlash® Connector
2.11.10 Audio Output Connector
CN Label: CN4
CN Type:
4-pin connector
CN Location:
See
Figure 2-9
CN Pinouts:
See
Table 2-10
The audio output connector connects to speakers.

IEI Technology AFL-xxx-9103 Specifications

General

Brand	IEI Technology
Model	AFL-xxx-9103
Category	Touch Panel
Language	English
