4.5.8 Panel Resolution
This jumper selects the video resolution.
JP5 Description
Open 800 x 600, 18-bit
1-2 1024 x 768, 18-bit
3-4 1280 x 1024, 36-bit
5-6 1280 x 1024, 48-bit
Table 4-13: Panel Resolution Settings
4.5.9 Touch Panel Type
The touch panel type selects whether the connected touch panel is a 4-wire or 5-wire
touch panel.
J1 DESCRIPTION
1-2 5-wire
3-4 4-wire
Table 4-14: Touch Panel Type
