IEI Technology AFL-xxx-9103 User Manual

AFL-xxx-9103 Panel PC
Page 30
PIN DESCRIPTION PIN DESCRIPTION
1 WAKE# 2 VCC3
3 RESERVED 4 GND
5 RESERVED 6 VCC1.5
7 CLKREQ# 8 NC
9 GND 10 NC
11 REFCLK- 12 NC
13 REFCLK+ 14 NC
15 GND 16 NC
17 NC 18 GND
19 NC 20 NC
21 GND 22 PERST#
23 PERn0 24 VCC3_AUX
25 PERp0 26 GND
27 GND 28 VCC1.5
29 GND 30 SMB_CLK
31 PETn0 32 SMB_DATA
33 PETp0 34 GND
35 GND 36 USB_DATA-
37 RESERVED 38 USB_DATA+
39 RESERVED 40 GND
41 RESERVED 42 LED_WWAN#
43 RESERVED 44 LED_WLAN#
45 RESERVED 46 LED_WPAN#
47 RESERVED 48 VCC1.5
49 RESERVED 50 GND
51 RESERVED 52 VCC3
Table 2-5: Front Panel Connectors
2.11.6 Backlight Connector
CN Label: CN5
CN Type:
6-pin box header
